Ham Radio Technician Visual Cram Map
A Diagram-First Guide to FCC Element 2 Concepts, Rules, Calculations, and All 409 Official Question IDs
A diagram-first companion to the 2026–2030 Technician Class question pool, connecting electricity, components, antennas, signals, operating rules and safety to all 409 official question IDs.
Available formats: Kindle, paperback.
About this book
The Technician exam can look like 409 unrelated facts. This book turns the current 2026–2030 Element 2 pool into a smaller set of connected visual models.
Follow plain-English maps for electricity, components, radio blocks, troubleshooting, propagation, antennas, signals, station setup, operating, rules and safety. Then use the complete question-ID crosswalk to route any missed practice item back to the concept that explains it.
Inside:
- diagram-first explanations for concepts beginners commonly mix up;
- compact formula, signal-path, operating, rules and safety review routes;
- exact official T-1, T-2 and T-3 figure keys;
- official-pool anchors for every group;
- a deterministic crosswalk covering all 409 current question IDs.
This is not another pile of practice tests. Use it beside a free randomized exam tool: learn the model here, practise there, and diagnose every miss by ID.
Built for the corrected NCVEC Technician Class Element 2 question pool released February 19, 2026, effective July 1, 2026 through June 30, 2030. Independent study aid; not affiliated with or endorsed by the FCC, NCVEC, ARRL or any examination provider. No passing result is promised.
